Micropiles: Commercial Building, St. Petersburg, FL
Table of Contents
Contact us anytime!
[cs_content][cs_element_section _id=”1″ ][cs_element_row _id=”2″ ][cs_element_column _id=”3″ ][cs_element_headline _id=”4″ ][/cs_element_column][/cs_element_row][/cs_element_section][cs_element_section _id=”5″ ][cs_element_row _id=”6″ ][cs_element_column _id=”7″ ][cs_element_video _id=”8″ ][cs_element_gap _id=”9″ ][/cs_element_column][cs_element_column _id=”10″ ][cs_element_headline _id=”11″ ][cs_element_gap _id=”12″ ][cs_element_text _id=”13″ ][cs_element_gap _id=”14″ ][cs_element_headline _id=”15″ ][cs_element_headline _id=”16″ ][cs_element_headline _id=”17″ ][cs_element_gap _id=”18″ ][cs_element_button _id=”19″ ][cs_element_social _id=”20″ ][cs_element_social _id=”21″ ][cs_element_social _id=”22″ ][cs_element_social _id=”23″ ][/cs_element_column][/cs_element_row][/cs_element_section][cs_element_section _id=”24″ ][cs_element_layout_row _id=”25″ ][cs_element_layout_column _id=”26″ ][cs_element_text _id=”27″ ][cs_element_text _id=”28″ ][/cs_element_layout_column][/cs_element_layout_row][/cs_element_section][cs_element_section _id=”29″ ][cs_element_layout_row _id=”30″ ][cs_element_layout_column _id=”31″ ][cs_element_text _id=”32″ ][cs_element_text _id=”33″ ][/cs_element_layout_column][/cs_element_layout_row][/cs_element_section][cs_element_section _id=”34″ ][cs_element_layout_row _id=”35″ ][cs_element_layout_column _id=”36″ ][cs_element_text _id=”37″ ][cs_element_text _id=”38″ ][/cs_element_layout_column][/cs_element_layout_row][/cs_element_section][cs_element_section _id=”39″ ][cs_element_row _id=”40″ ][cs_element_column _id=”41″ ][cs_element_image _id=”42″ ][cs_element_image _id=”43″ ][cs_element_gap _id=”44″ ][/cs_element_column][cs_element_column _id=”45″ ][cs_element_image _id=”46″ ][cs_element_image _id=”47″ ][/cs_element_column][/cs_element_row][/cs_element_section][/cs_content][cs_content_seo]Raymond James Tower
St. Petersburg, FL
CLIENT: Raymond James
ENGINEER: GHD Services
MARKET: Commercial
SOLUTION: Deep Foundation
SERVICE: Micropiles
Deep Foundation for a 4-story commercial building
Support the southern perimeter of building
Hydraulically Pressed Micropiles
Project PDF
Project
The project is a 4-story commercial office building located in St. Petersburg, FL. A vertical difference in elevation of up to 2 inches was measured within the floor. The highest elevations of the floor were measured along the south wall of the building, while the lowest elevations were measured along the southern perimeter of the concrete slab. The Geotechnical Engineer of Record recommended a deep foundation solution of hydraulically pressed micropiles installed.
Challenge
• Difficulty penetrating the concrete foundation demanded the use of a specialized hydraulic drill press. • Limited movement around the site, due to building being open for business.
Solution
Helicon worked alongside the geotechnical design team to develop a microplile design submittal. The micropile program was designed to meet the design load criteria. Micropiles are high-performance, high-capacity drilled deep foundation elements that transfer the structural load through unsuitable soil layers to competent foundation soils. The loads are transferred from the foundation through the steel and grout of the micropile and shed to surrounding rock or soil via high values of friction. Efficient planning & coordination was key to overcoming the challenges & limitations. 8 micropiles were installed from site grade to depths up to 50 feet. Helicon collaborated with the Geotechnical Engineer of Record throughout the work and confirmed all recommended criteria were followed. The micropile work was successfully completed on time and within budget.
