Excavation Assist Using Polyurethane Grout: A Smarter Alternative to Sheet Piles

Jul 3, 2025 | Poly Foam Grout, Commercial Blog Posts, Ground Improvement, Permeation Grout, Residential Blog Posts, Soil Stabilization

When Excavation Gets Tight, Think Beyond Sheet Piles

Excavating near an existing structure — like a home, commercial building, or utility line — often requires soil support to avoid collapse or damage. For decades, the go-to solution has been sheet piling: driving steel sheets into the ground to create a temporary shoring wall.

But sheet piles come with serious downsides:

  • High cost
  • Vibration risks to nearby structures
  • Heavy equipment needs
  • Limited accessibility in tight areas

Today, there’s a smarter, faster, and more cost-effective alternative for excavation support: polyurethane injection permeation grouting.

What Is Polyurethane Grout Injection for Excavation Assist?

Helicon uses a permeation grout called AP600, a low-viscosity polyurethane resin, to stabilize soil and build a temporary underground wall. This non-expanding material seeps into fine-grained soils (like sand), then hardens into a concrete-like mass — turning unstable ground into a solid excavation shoring wall.

This “grout curtain” supports the soil adjacent to your dig site, providing excavation assist without the need for steel sheets or heavy machinery.

Common Use Cases for Polyurethane Shoring Walls

  • Excavations next to homes or commercial buildings
  • Tight-access job sites where pile driving equipment won’t fit
  • Urban infill projects with vibration-sensitive neighbors
  • Value-engineered alternatives to high-cost sheet pile installation
  • Projects with depth requirements up to ~15 feet

Sheet Piles vs. Polyurethane Injection

FeatureSheet PilesPolyurethane Injection (AP600)
CostHigh (steel + installation)Significantly lower
VibrationHigh — risk to nearby buildingsVery low — minimal disruption
Access RequirementsRequires large equipmentWorks in tight or restricted areas
NoiseLoud during drivingQuiet installation
Environmental ImpactSteel removal adds costGrout is inert and stays in place
Max Effective Depth30–60+ ftUp to 15 ft (ideal range)

How It Works: The Grout Curtain Process

1. Plan and Mark

The contractor provides excavation depth and layout. Helicon’s team maps out injection lines using stakes or string to ensure precision.

2. Drill Injection Holes

Using compact equipment, injection rods are installed at a slight 3–5° angle away from the excavation. Rods are spaced 18″ apart, and for depths >8 feet, a second staggered row is added 18″ behind the first.

3. Inject AP600 Grout

Each rod is used to inject grout in 1-foot intervals from bottom to top:

  • Start 2 feet below planned excavation depth
  • Inject 1 gallon per vertical foot
  • Grout permeates and hardens in ~2 minutes per foot
  • Stops 1 foot below surface to avoid breakout

The non-expanding grout permeates the soil, turning it into a rigid, cohesive wall capable of holding back earth during excavation.

4. Excavate Safely

Once cured (typically within 24 hours), excavation can begin — but mechanical equipment must stay 2+ feet away from the grout wall. Final trim is done by hand or hydro-vac.

Soil Types That Work Best

AP600 is designed for permeation, not expansion. It’s ideal for:

Sand
Fine silts
Granular soil types

⚠️ Less effective in:

  • High plasticity clay (which resists permeation and may not need shoring)
  • Organic material or very dense clay (which can fracture or lens)

That’s why soil boring reports or geotechnical testing are important for project design.

Depth Recommendations

Excavation DepthInjection Strategy
≤ 8 ftSingle row (18” spacing)
8–15 ftDouble staggered row
> 15 ftSheet piles may be better

Helicon’s polyurethane grout walls are most effective up to 15 feet. Beyond that, multiple injection rows become inefficient, and other structural shoring may be needed.

Cost Savings & ROI

Switching from sheet piles to Helicon’s polyurethane grout method can save:

  • Tens of thousands on residential jobs
  • Up to six figures on larger commercial projects

Savings come from:

  • No need for steel or removal
  • Smaller crews and equipment
  • Shorter install times
  • No costly vibration damage

Combine with Underpinning When Needed

When adjacent structures need more than soil support, Helicon can pair permeation grouting with:

  • Push piers (steel-driven deep supports)
  • Drilled piers (poured concrete or steel)

This hybrid approach is ideal for:

  • Older buildings
  • Structures with active settlement
  • High-load foundations near deep excavation

Real-World Examples

On a commercial project, the contractor and engineer originally planned to use traditional sheet piles for shoring to support the foundation of a commercial building. Helicon collaborated with the engineer to develop a value-engineered alternative: a polyurethane grout curtain combined with steel push piers installed under the building’s foundation. The shoring wall and underpins were completed within five days, excavation proceeded safely, and the client saved over $300,000 compared to the original sheet pile proposal.

On a recent project with access constraints, Helicon installed a polyurethane grout curtain within 2 feet of a residential foundation. Traditional sheet piles weren’t an option due to equipment access and budget. The wall was in place within two days, excavation followed safely, and the client saved over $70,000 compared to a sheet pile proposal.

Safety Guidelines

  • Injection starts 2’ below excavation depth
  • Do not excavate within 24” of cured grout with equipment
  • Always hand dig near the grout wall
  • Excavation limit line should be marked 33” back from rods (accounting for rod angle)

Why Engineers and Contractors Choose Helicon

  • Florida-based foundation experts
  • Proven track record in geotechnical solutions
  • Fast mobilization and project turnaround
  • Seamless integration with GCs, engineers, and owners
  • Full service: injection + underpinning + stabilization

Optimize Your Excavation Support Plan

If you’re a contractor, builder, or geotechnical engineer working on an excavation project in tight quarters, don’t default to sheet piles. Helicon’s polyurethane injection method is often:

  • Faster
  • Cheaper
  • Cleaner
  • More flexible

We specialize in value-engineering shoring solutions that reduce project costs and risks while maintaining structural safety and soil integrity.

Let’s Put Your Excavation Project on Solid Ground

Have a project where you’re excavating near a structure? Let’s collaborate. Helicon offers:
